FP0 HardwareAnalog I/O Unit
4-6
Matsushita Electric Works (Europe) AG
DescriptionItem
Overall
precision
Voltage/
current range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
±1% F.S. or less (0 to 55°C/32 to 131°F)
±0.6% F.S. or less (25°C/77°F)
Thermocouple range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Offset error (0 to 55°C/32 to 131°F):
±2% F.S. or less (K type thermocouple) (see note 4)
±2.7% F.S. or less (J type thermocouple) (see note 4)
±5.8% F.S. or less (T type thermocouple) (see note 4)
Linearity error: ±1% F.S. or less(0 to 55°C/32 to 131°F)
Input Voltage range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1MΩ or more
impedance
Current range
250Ω
Absolute Voltage range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
±15V
maximum input
Current range
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
+30mA
Insulation method (see note 5)
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Between analog input terminal to FP0 internal circuit:
photocoupler insulation (non-insulated between analog inputs)
Between analog input terminal to analog I/O unit external power supply:
insulation-type DC/DC converter
Between analog input terminal to analog output terminal: insulation-type
DC/DC converter
Number of input contact points
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
32 input contact points:
16 points for 1st half: analog input CH0 data (WX2) (see note 6)
16 points for last half: analog input CH1 data (WX3) (see note 6)
Notes
1) A temperature lower than the terminal temperature of the
analog I/O unit cannot be measured.
2) A temperature higher than the terminal temperature of the
analog I/O unit cannot be measured.
3) The time noted below is required before the analog data is
reflected in the control unit input.
0ms to
scan time
1ms × number of
expansion units
0V
10V
K0
K2000
Conversion
time: (1ms)
Refresh
standby
Refresh
Analog input
WX2
4) See page 4-16, “Boosting the Precision of the Thermocouple
Range.”
To Next Page
