84-05 : VOIPU IP Address Setup
Networking ◆ 229
84-05 : VOIPU IP Address Setup
Description
Use Program 84-05 : VOIPU IP Address Setup to deÞne the IP Address of the VOIPU PCB.
Input Data
Conditions
The system programming must be exited before these program options to take affect.
Feature Cross Reference
● VoIP
Level:
Aspire S Aspire M/L/XL
IN • Available. • Available.
• Applicable to IP and ISDN Networking. • Applicable to IP and ISDN Networking.
Slot Number 01-16
Item Description Input Data Default Related Program
01 IP Address
Sets the IP Address of each
VOIPU PCB.
Each slot (1-16) on the
Aspire has a setting. The IP
Address will be increased in
accordance with the slot
number.
If Program 84-04 is enabled,
this setting will be ignored
1.0.0.1–126.255.255.254
128.1.0.1–191.254255.254
192.0.1.1–223.255.254.254
Slot 1: 172.16.0.20
Slot 2: 172.16.0.21
Slot 3: 172.16.0.22
Slot 4: 172.16.0.23
Slot 5: 172.16.0.24
Slot 6: 172.16.0.25
Slot 7: 172.16.0.26
Slot 8: 172.16.0.27
Slot 9: 172.16.0.28
Slot 10: 172.16.0.29
Slot 11: 172.16.0.30
Slot 12: 172.16.0.31
Slot 13: 172.16.0.32
Slot 14: 172.16.0.33
Slot 15: 172.16.0.34
Slot 16: 172.16.0.35
84-04
This become invalid
data if Program 84-04
is set to 1:Enable.
02 LAN Interface
This sets the mode for the
NIC (Network Interface
Card) on the VOIPU. This
can usually be set to Auto
Detect.
0 = Auto Detect
1 = 100 Mbps, Full Duplex
2 = 100 Mbps, Half Duplex
3 = 10 Mbps, Full Duplex
4 = 10 Mbps, Half Duplex
0
To Next Page
