NEC Aspire Series User Manual

Appendix
Aspire Networking Examples
Networking ◆ 241
After programming, each system must be reset in order for the IP address changes to take affect.
Aspire A Aspire B
Program 10-12-01
• IP Address of the NTCPU = 172.16.0.10
Program 10-12-02
• Subnet Mask = 255.255.0.0
Program 10-12-03
• Default Gateway = 192.168.1.100
(this is the router’s inside address)
The installation site’s IT personnel
should be able to provide these IP
addresses.
Program 10-12-01
• IP Address of the NTCPU = 172.16.0.11
Program 10-12-02
• Subnet Mask = 255.255.0.0
Program 10-12-03
• Default Gateway = 192.168.1.100
(this is the router’s inside address)
The installation site’s IT personnel
should be able to provide these IP
addresses.
Program 10-20-01 TCP Port Setup
• Device 4 = 30000
Program 10-20-01 TCP Port Setup
• Device 4 = 30000
Program 10-27-01 Destination IP Address (as
entered in Aspire B’s Program 10-12-01) and
port number for each ID
• ID 1 = IP Address 172.16.0.11
• Procedure port must be set to 1730
Program 10-27-01 Destination IP Address (as
entered in Aspire A’s Program 10-12-01) and
port number for each ID
• ID 1 = IP Address 172.16.0.10
• Procedure port must be set to 1730
Program 11-01-01 System Numbering
• Dial 3x = 3 digit, Type 2 (Intercom)
• Dial 4x = 3 digit, Type 8 (Networking),
ID=1
Program 11-01-01 System Numbering
• Dial 3x = 3 digit, Type 8 (Networking),
ID=1
• Dial 4x = 3 digit, Type 2 (Intercom)
Program 20-01-04 BLF Refresh Rate
• BLF Refresh Rate = 30
For Hotline lamping over the network.
Program 20-01-04 BLF Refresh Rate
• BLF Refresh Rate = 30
For Hotline lamping over the network.
Program 84-05-01 (VOIPU card in slot 2)
• IP Address of the VOIPU PCB =
172.16.0.21
The installation site’s IT personnel
should be able to provide these IP
addresses.
Program 84-05-01 (VOIPU card in slot 3)
• IP Address of the VOIPU PCB =
172.16.0.22
The installation site’s IT personnel
should be able to provide these IP
addresses.
Program 84-06-01 VOIPU Setup
• DTMF Behavior = 2 (Out of Band)
Program 84-06-01 VOIPU Setup
• DTMF Behavior = 2 (Out of Band)
Program 84-12-31 H.323 Phone CODEC
• DTMF Relay Mode = 1 (RFC2833)
Program 84-12-31 H.323 Phone CODEC
• DTMF Relay Mode = 1 (RFC2833)
Program 84-02-35 Fast Start
• Enable Fast Start
Program 84-02-35 Fast Start
• Enable Fast Start

NEC Aspire Series Specifications

General

Series	Aspire
Protocols	SIP, H.323
Lines	IP
Extensions	Digital, IP
Voicemail	Integrated Voicemail System
Networking	IP Networking
Power Supply	100-240V AC, 50/60Hz
Dimensions	Varies depending on the system module
Weight	Varies depending on the system module
