NMC-PRO Installation Manual
28Page
• NetSense, page 28
• Ech2o 5, page 29
• NetSense / Ech2o 5 Jumper Position, page 31
4.3.2.1 NetSense
• NetSense Specifications
• NetSense Installation
4.3.2.1.1 NetSense Specifications
• Stainless Steel with plastic coating
• All electronics are sealed in water-proof epoxy
• Temperature range:
Operating: 0° to 50° C
Storage: -20° to 60° C
• Output format: 0.5 - 5.0 mA
• Power requirements: 5.5 - 18 VDC, 10 - 20 mA (max)
• Accuracy: 1% Volumetric Soil Moisture
Note: Less accuracy may be experienced in some cases
• Connection: 3 pin Switchcraft connector EN3C3M
• Dimensions (cm): 9.5 W x 3.2 D x 27.0 L
• Weight: 0.5 kg.
• Typical measurement field is 4 cm in all directions from the outside element
4.3.2.1.2 NetSense Installation
Connect as follows:
• Yellow-Green to COM
• Brown to +12V
• Blue to inputs 1 – 11; jumper 0 – 5V (In the example below, Blue is attached to Terminal 8.)
