3 Click Apply/Save.
Limiting the downstream rate
1 Navigate to the QoS Queue Configuration page to add a queue for the LAN interface, for example:
Figure 140 – QoS Queue Configuration
1 On the QoS Classification page, add a rule to limit the downstream rate, for example:
Classification Criteria:
Class Interface: the appropriate WAN interface
Classification Results:
Class Queue: the queue that was created on Step 1
Set rate-limit: set according to your preference
