VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP
Web based configuration interface
First-time setup wizard
Note – While we highly recommend that you set up your new router using the First-time Setup Wizard (Basic Setup), it is possible to
configure your new router directly from the Advanced Setup features.
It is also possible to initially set up your router using the Basic Setup wizard and then later fine-tune your configuration using
the Advanced Setup tools.
Please follow the steps below to configure your NF18ACV Wireless router via the web based configuration wizard.
1 Open a web browser and type http://192.168.20.1/ into the address bar at the top of the window.
2 At the login screen, type admin in the username and password field, then click the Login button.
Note – ‘admin’ is the default username and password for the unit.
3 Click on the Basic Setup menu item on the left side of the screen.
Figure 3 – NF18ACV router – Select Basic Setup
4 To run the Wizard having all the basic set up details that your system requires, select the Wan Connection type that
you will be using: ADSL, VDSL or Ethernet WAN
ADSL
a Select ADSL and click the Next button.
