NetCommWireless NF18ACV User Manual

48 of 131
User Guide
© NetComm Wireless 2017
Field
Description
Select an
Application or
Custom Application
A user can select a pre-configured application from the list or select the Custom
Application option to create custom application settings.
Trigger Port Start
Enter the starting trigger port number (when you select Custom Application).
When an application is selected the port range values are automatically entered.
Trigger Port End
Enter the ending trigger port number (when you select Custom Application).
When an application is selected the port range values are automatically entered.
Trigger Protocol
Options include TCP, UDP or TCP/UDP.
Open Port Start
Enter the starting open port number (when you select Custom Application). When
an application is selected the port range values are automatically entered.
Open Port End
Enter the ending open port number (when you select Custom Application). When
an application is selected the port range values are automatically entered.
Open Protocol
Options include TCP, UDP or TCP/UDP.
Table 17 – NAT -- Port Trigger Configuration settings
DMZ Host
The NF18ACV will forward IP packets from the Wide Area Network (WAN) that do not belong to any of the applications
configured in the Virtual Servers table or being used in the Virtual Server table to the DMZ host.
Enter the Host’s IP address and click Apply to activate the DMZ host. To deactivate the DMZ Host function, clear the IP
address field and press the Save/Apply button.
Figure 48 – NAT – DMZ Host settings
Note that LAN Loopback can also be enabled.
LAN Loopback allows the LAN host to access another LAN host/server via the external IP Address of the router. Without NAT
loopback you must use the internal IP address of the device when on the LAN side.
