The following options are available to configure:
Enter the Local IP Address to use for the NF18ACV.
Enter the subnet mask to define the subnet of the Local Network.
Enable IGMP Snooping and select the IGMP Snooping mode to use. Standard:
allow all multicast traffic to LAN clients. Blocking: only allow multicast
subscribed clients to receive multicast packets.
Enable the LAN side firewall to restrict traffic between LAN host-LAN hosts
and WiFi Clients.
Select to enable or disable the DHCP server and enter the start and end
address for the DHCP IP Address pool.
Disabled DHCP server, and relay all request to external server specified by the
IP address.
Configure the second
IP Address
This option enables you to set a secondary IP Address for the NF18ACV
Table 14 – IPv4 Autoconfig settings table
You can also reserve DHCP Addresses for specific hosts as shown below:
Figure 41 – Enter DHCP Static IP Addresses
To set a DHCP reservation, enter the MAC Address of the chosen host and IP to use and then click Apply/Save.
The NF18ACV enables you to set the DHCP options which are provided to hosts attempting to connect to the DHCP server.
These options should not normally need to be set or changed. Click Apply/Save to save the new LAN configuration settings.
