No.
Interface
Description
7
Power supply jack
Connection point for the included power adapter. Connect the power supply
here.
Table 6 – Rear interface table
Left Side
Figure 2 – NF18ACV router side view
No
Interface
Description
1
2.4G WPS button
Press the 2.4G WPS button to activate the WPS
PBC pairing function for the 2.4GHz radio.
2
5G WPS button
Press the 5G WPS button to activate the WPS
PBC pairing function for the 5GHz radio.
3
On/Off button
Toggles the power on and off.
Table 7 – Side interface table
1
2
3
