LAN VLAN Setting
This page allows you to specify a LAN port to apply VLAN tagging to.
Figure 43 – Specify a LAN port for VLAN tagging
Select the LAN port using the drop down menu, then click the Add button. Enter the VLAN ID and in the Pbits field, enter a
value from 0-7 indicating the priority bits that dictates the priority of the VLAN.
Click Apply/Save when you have finished.
NAT
Virtual Servers
Virtual Servers (also commonly referred to as port forwarding) allow you to direct incoming traffic from the WAN side to the
Internal network host with a private IP address on the LAN side.
Figure 44 – NAT -- Virtual Server list
Click the Add button to add a virtual server.
