• Specify XXX to block http://www.badstuff.com/xxx.html.
• Specify .com if you want to allow only sites with domain suffixes such as .edu or .gov.
• Enter a period (.) to block all Internet browsing access.
7. Click the Add Keyword button.
The keyword or domain is added to the Block sites containing these keywords or domain names field (which
is also referred to as the blocked list).
8. To add more keywords or domains, repeat Step 6 and Step 7.
The keyword list supports up to 32 entries.
9. Click the Apply button.
Your settings are saved.
Remove a Keyword or Domain From the Blocked List
If you no longer need a keyword or domain on the blocked list, you can remove the keyword or domain.
To remove a keyword or domain from the blocked list:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Security > Block Sites.
The Block Sites page displays.
5. In the Block sites containing these keywords or domain names field, select the keyword or domain.
6. Click the Delete Keyword button.
The keyword or domain is removed from the blocked list.
7. Click the Apply button.
Your settings are saved.
Control Access to the Internet
131
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

Table of Contents

Other manuals for NETGEAR D7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR D7000 and is the answer not in the manual?

NETGEAR D7000 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
ModulationPSK
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
Memory card slot(s)No
Ethernet LAN (RJ-45) ports5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
DSL specificationVDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management-
Firewall securitySPI, NAT
Security algorithmsWPA, WPA2-PSK, WPS
Product typeTabletop router
Product colorBlack
Housing materialPlastic
Flash memory128 MB
Internal memory256 MB
Processor cores2
Processor frequency1000 MHz
Windows operating systems supportedWindows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables includedLAN (RJ-45), Phone (RJ-11)
Supported network protocolsIPv6
Power source typeAC
Package typeBox
Weight and Dimensions IconWeight and Dimensions
Depth185 mm
Width285 mm
Height50 mm
Weight750 g
