NETGEAR D7000 User Manual

Set Up a VPN Connection
A virtual private network (VPN) lets you use the Internet to securely access your network when you are not home.
This type of VPN access is called a client-to-gateway tunnel. The computer is the client, and the modem router is
the gateway.To use the VPN feature, you must log in to the modem router and enable VPN, and you must install
and run VPN client software on the computer.
The modem router does not support iOS or Android VPN client software.Note
VPN uses DDNS or a static IP address to connect with your modem router.
To use a DDNS service, register for an account with a host name (sometimes called a domain name).You use the
host name to access your network. The modem router supports these accounts: NETGEAR, No-IP, and Dyn. See
Set Up and Manage Dynamic DNS on page 176.
If your Internet service provider (ISP) assigned a static WAN IP address (such as 50.196.x.x or 10.x.x.x) that never
changes to your Internet account, the VPN can use that IP address to connect to your home network.
Specify VPN Service in the Modem Router
You must specify the VPN service settings in the modem router before you can use a VPN connection.
To specify the VPN service:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > VPN Service.
The VPN Service page displays.
5. Select the Enable VPN Service check box.
By default, the VPN uses the UDP service type and uses port 12974. If you want to customize the service type
and port, we recommend that you change these settings before you install the OpenVPN software.
6. To change the service type, scroll down and select the TCP radio button.
7. To change the port, scroll down to the Service Port field, and type the port number that you want to use.
Use VPN to Access Your Network
250
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
