DescriptionField
Select the protocol (TCP or UDP) that is associated with the service or
application. If you are unsure, select TCP/UDP.
Protocol
Enter the start port for the service or application.Starting Port
If the service or application uses a range of ports, enter the end port for the
range. If the service or application uses a single port, repeat the port number
that you entered in the Starting Port field.
Ending Port
Enter the name of the custom service or application.Service Type/User Defined
10. Specify which devices on your LAN (or LAN users) are affected by the rule, based on their IP addresses:
• Only This IP Address. Enter the required address in the fields to apply the rule to a single device on your
LAN.
• IP Address Range. Enter the required addresses in the start and end fields to apply the rule to a range of
devices.
• All IP Addresses. All computers and devices on your LAN are covered by this rule.
By default, the All IP Addresses radio button is selected.
11. Click the Add button.
The new rule is added to the Service Table on the Block Services page.
Change an Outbound Firewall Rule
You can change an existing outbound firewall rule.
To change an outbound firewall rule:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
Control Access to the Internet
137
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
