Manage Port Forwarding and Port

Triggering

You can use port forwarding and port triggering to set up rules for Internet traffic for services and applications.You need

networking knowledge to set up these features.

This chapter includes the following sections:

• Manage Port Forwarding to a Local Server for Services and Applications on page 260

• Manage Port Triggering for Services and Applications on page 265

259
