NETGEAR D7000 User Manual

Manually Set Up a VDSL Internet Connection
You can view or change the modem router’s VDSL Internet connection settings manually. The following sections
describe the options that are available to you to manually set up the VDSL Internet connection:
• Specify a VDSL Connection Without a Login Requirement on page 60
• Specify a VDSL Connection With a Login Requirement and PPPoE Service on page 65
Some ISPs require that you register on their website before you can obtain Internet service.
Follow the directions that your ISP gave you.
Note
Specify a VDSL Connection Without a Login Requirement
If you want to manually configure the VDSL connection settings, use the information that your ISP gave you to
connect to your Internet service. If you cannot find this information, contact your ISP. Entering incorrect information
might prevent the modem router from connecting to the Internet.
The modem router provides a virtual Internet interface and a virtual IPTV interface. In most situations, you only need
to configure the Internet interface. If you use one or more IPTV devices, you might also need to configure the IPTV
interface. Follow the directions that your ISP gave you.
If you must configure the IPTV interface, first use the following procedure to configure the
Internet interface.Then, repeat the procedure to configure the IPTV interface.
Note
To view or specify the settings for a VDSL Internet connection that does not require a login:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Internet.
The Internet Setup page displays.
5. From the Select Country menu, select the country in which you use the modem router.
The Select Country menu is not available in all countries and might be masked out.
6. From the Select Internet Service Provider menu, select the Internet service provider (ISP) that you are using.
Manage the Internet Settings Manually
60
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
