7. To terminate the Internet connection when the connection is active, click the Disconnect button.
8. Click the Close Window button.
The pop-up window closes.
View Devices Currently on the Network
You can view the active wired and WiFi devices in both the network to which the modem router is connected and
the modem router network. If you do not recognize a WiFi device, it might be an intruder.
To display the wired and WiFi devices:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
The Attached Devices page displays.
Wired devices are connected to the modem router with Ethernet cables.WiFi devices are connected to the
modem router through the WiFi network, in either the 2.4 GHz band or the 5 GHz band.
The following table describes the fields on the Attached Devices page.
DescriptionField
The status of the device in the network (Allowed or Blocked).Status
The device name, if detected.Device Name
The IP address that the modem router assigned to the device when it joined the network. This
address can change when a device is disconnected and rejoins the network.
IP Address
The unique MAC address.The MAC address does not change and is usually shown on the product
label.
MAC Address
5. To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
Manage the Modem Router and Monitor the Traffic
236
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
