A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > WAN Setup.
The WAN Setup page displays.
5. To enable a port scan and disable DoS protection, select the Disable Port Scan and DoS Protection check
box.
6. To enable the modem router to respond to a ping, select the Respond to Ping on Internet Port check box.
7. Click the Apply button.
Your settings are saved.
Set Up a Default DMZ Server
The default DMZ server feature is helpful when you are using some online games and videoconferencing applications
that are incompatible with Network Address Translation (NAT).The modem router is programmed to recognize some
of these applications and to work correctly with them, but other applications might not function well. In some cases,
one local computer can run the application correctly if the IP address for that computer is entered as the default
DMZ server.
WARNING:
DMZ servers pose a security risk. A computer designated as the default DMZ server
loses much of the protection of the firewall and is exposed to exploits from the
Internet. If compromised, the DMZ server computer can be used to attack other
computers on your network.
The modem router usually detects and discards incoming traffic from the Internet that is not a response to one of
your local computers or a service or application for which you set up a port forwarding or port triggering rule. Instead
of discarding this traffic, you can direct the modem router to forward the traffic to one computer on your network.
This computer is called the default DMZ server.
To set up a default DMZ server:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
Manage the WAN and LAN Network Settings
204
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

Table of Contents

Other manuals for NETGEAR D7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR D7000 and is the answer not in the manual?

NETGEAR D7000 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
ModulationPSK
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
Memory card slot(s)No
Ethernet LAN (RJ-45) ports5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
DSL specificationVDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management-
Firewall securitySPI, NAT
Security algorithmsWPA, WPA2-PSK, WPS
Product typeTabletop router
Product colorBlack
Housing materialPlastic
Flash memory128 MB
Internal memory256 MB
Processor cores2
Processor frequency1000 MHz
Windows operating systems supportedWindows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables includedLAN (RJ-45), Phone (RJ-11)
Supported network protocolsIPv6
Power source typeAC
Package typeBox
Weight and Dimensions IconWeight and Dimensions
Depth185 mm
Width285 mm
Height50 mm
Weight750 g
