To add a QoS rule for a device:

1. Launch a web browser from a computer or WiFi device that is connected to the network.

2. Enter http://www.routerlogin.net.

A login window opens.

3. Enter the modem router user name and password.

The user name is admin.The default password is password.The user name and password are case-sensitive.

The BASIC Home page displays.

4. Select ADVANCED > Setup > QoS Setup.

5. Select the By Device radio button.

Optimize Performance

148

Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
