NETGEAR D7000 User Manual

5. Click the Edit button.
The previous figure shows a USB device attached to the modem router.
6. In the Available Network Folders table, select a device.
7. Click the Create Network Folder button.
If this pop-up window does not display, your web browser might be blocking pop-ups. If it is, change the browser
settings to allow pop-ups.
8. From the USB Device menu, select the USB drive.
We recommend that you do not attach more than one drive to each USB port (for example,
through a USB hub).
Note
9. Click the Browse button.
Another pop-up window opens.
10. Navigate to the folder in which you want to create a new share and select the folder.
11. Click the OK button.
Share a Storage Device
169
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
