The BASIC Home page displays.
4. Select ADVANCED > ADVANCED Home.
The ADVANCED Home page displays.
5. In the Internet Port pane, click the Show Statistics button.
The Show Statistics pop-up window opens.
The following table describes the fields and columns of the Show Statistics pop-up window.
DescriptionField or Column
The time elapsed since the modem router was last restarted.System Up Time
The statistics for the WAN (Internet over Ethernet) port, LAN (Ethernet) ports, WLAN b/g/n
port, and WLAN a/n/ac port. For each port, the page displays the information that is
described in this table.
Port
The link status of the port.Status
The number of packets that were transmitted on this port since reset or manual clear.TxPkts
The number of packets that were received on this port since reset or manual clear.RxPkts
The number of packets that collided on this port since reset or manual clear.Collisions
The number of bytes per second that were transmitted on this port since reset or manual
clear.
Tx B/s
The number of bytes per second that were received on this port since reset or manual
clear.
Rx B/s
The time elapsed since this port acquired the link.Up Time
ADSL Link
In addition to the xDSL firmware version, the page displays the ADSL link information that is described in this table.
The downstream and upstream link rates in Kbps.Link Rate
The downstream and upstream line attenuation (LATN) in dB.The LATN expresses the
signal quality.
Line Attenuation
Manage the Modem Router and Monitor the Traffic
232
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
