7. Click the Add Custom Service button.
8. Specify a new port forwarding rule with a custom service or application as described in the following table.
DescriptionField
Enter the name of the custom service or application.Service Name
Select the protocol (TCP or UDP) that is associated with the service or application.
If you are unsure, select TCP/UDP.
Service Type
Enter one or more port numbers, one or more ranges of port numbers, or a combination of
both.
Divide ports and port ranges by commas.
Starting Port
External port range
Specify the internal ports by one of these methods:
• Leave the Use the same port range for Internal port check box selected.
• In the Internal Port Range field, enter one or more port number, one or more ranges of
port numbers, or a combination of both.
Divide ports and port ranges by commas.
Internal port range
Either enter an IP address in the Service IP address field or select the radio button for an
attached device that is listed in the table.
Service IP Address
9. Click the Apply button.
Your settings are saved. The rule is added to the table on the Port Forwarding / Port Triggering page.
10. To arrange the table entries by internal IP address, click the Arrange by internal IP button.
The lowest internal IP address displays at the top and the highest at the bottom.
Manage Port Forwarding and Port Triggering
262
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
