NETGEAR D7000 User Manual

DescriptionField
These settings are not disabled but do not apply to a cable or fiber connection.You
can ignore these settings.
Transfer Mode
DSL Mode
Unless you changed the physical WAN interface settings so that the modem router
must use the Ethernet WAN interface (see Change the Physical WAN Connection
Preference on page 199), these settings are not disabled. However, these settings
do not apply to a cable or fiber connection and you can ignore them.
Multiplexing Method
VPI
VCI
Select the Use VLANID check box and enter the VLAN ID, as indicated by your ISP.
A VLAN ID might be required if you subscribe to both Internet service and IPTV
service. If your ISP did not provide you with a VLAN ID, leave the Use VLANID
check box cleared, which is the default setting.
Use VLANID
If your ISP provided you with a VLAN ID and a priority value, enter the priority value,
which is a number from 0 to 7.
You can enter a priority value only in combination with a VLAN ID. If your ISP did
not provide you with a priority value, leave the default setting (0).
Priority (0 ~ 7)
This setting is an option that applies to the IPTV interface only.
For information about configuring bridge mode, see Enable Bridge Mode for IPTV
Devices on page 202.
Bridge Mode
Enter the account name, as indicated by your ISP.This name might also be called
the host name.
If your ISP did not provide you with an account name or host name, leave the default
setting.
Account Name
Enter the domain name, as indicated by your ISP.
If your ISP did not provide you with a domain name, leave this field blank.
Domain Name
Internet IP Address or IPTV IP Address (depending on your selection in Step 7)
Your ISP uses DHCP to assign your IP address.Your ISP automatically assigns
these addresses.
Get Dynamically from ISP
Enter the IP address, IP subnet mask, and gateway IP address that your ISP assigned
you for static IP address service.The gateway is the ISP router to which your modem
router connects.
Use Static IP Address
These settings are not disabled but do not apply to a cable or fiber connection.You
can ignore these settings.
Use IP over ATM (IPoA)
Manage the Internet Settings Manually
72
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
