DescriptionField
These settings are not disabled but do not apply to a cable or fiber connection.You
can ignore these settings.
Transfer Mode
DSL Mode
Unless you changed the physical WAN interface settings so that the modem router
must use the Ethernet WAN interface (see Change the Physical WAN Connection
Preference on page 199), these settings are not disabled. However, these settings
do not apply to a cable or fiber connection and you can ignore them.
Multiplexing Method
VPI
VCI
Select the Use VLANID check box and enter the VLAN ID, as indicated by your
ISP.
A VLAN ID might be required if you subscribe to both Internet service and IPTV
service. If your ISP did not provide you with a VLAN ID, leave the Use VLANID
check box cleared, which is the default setting.
Use VLANID
If your ISP provided you with a VLAN ID and a priority value, enter the priority value,
which is a number from 0 to 7.
You can enter a priority value only in combination with a VLAN ID. If your ISP did
not provide you with a priority value, leave the default setting (0).
Priority (0 ~ 7)
This setting is an option that applies to the IPTV interface only.
For information about configuring bridge mode, see Enable Bridge Mode for IPTV
Devices on page 202.
Bridge Mode
For a PPP over Ethernet (PPPoE) connection, select PPPoE (PPP over Ethernet)
from the menu.
PPP over ATM (PPPoA) is not supported for a cable or fiber
connection.
Note
Encapsulation
Enter the login name that you use to log in to your Internet service, as indicated by
your ISP.
This login name is often an email address.
Login
Enter the password that you use to log in to your Internet service, as indicated by
your ISP.
Password
Enter the service name that you use to log in to your Internet service, as indicated
by your ISP.
Often, a service name is not required.
Service Name
Manage the Internet Settings Manually
76
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
