Connection
Digitax SF Instruction Manual
5. Descriptions of CN1 Connector Signals
4. Connections
5. Descriptions of CN1 Connector Signals
Pin No.
16
Interface Circuit
PO（Page 46） Control Mode
Signal Description P S T
HEND
Homing Complete
Open
･ State of Home Lost
･ During Homing
Close
State of Homing Complete
dif.
*
24
*
5
*
WARN1
Warning
Open
No warning
Close
A warning state is present
9
Appendix Warning Output
dif.
*
*
24
**
5
**
* In Standard I/O conguration
** In Optional I/O conguration.
