26
*1）
*2）
Item Specifications
Drive Model DA24A22, DA24A23
Compatible Motor
M □ 102 □ 2 □□
＊＊
）
AC Supply
Voltage Range
Three-phase 200 to 240 VAC ±10 %
50/60 Hz
Single-phase 200 to 240 VAC ±10 %
50/60 Hz
Input Current
Rated at 4.5 A (200 VAC input)
Rated at 3.8 A (230 VAC input)
Up to approximately 13 A
Rated at 8.6 A (200 VAC input)
Rated at 7.3 A (230 VAC input)
Up to approximately 23 A
I
n the Drive DA24A □□ (1 kW), single-phase can be used as the AC Supply source. To use single-
phase 200 to 240 VAC, connect it to the primary circuit L1 and L3 power connectors.
Notice
Use SELV
(Safety Extra Low Voltage/Non-Hazardous Voltage)
power supply with reinforced isolation from hazardous
voltage.
As a countermeasure against drive failure, install overcurrent protection or use power output capacity of no higher
than 100 W.
The current consumption values in the table assume that no I/O signals except the Servo-On signal are connected.
Current consumption by all I/O signals in use must be added up.
If multiple drives are to share control power, select a power source that will support the total inrush current of all
connected drives.
*3）
B
raking resistor values do not guarantee optimal performance. If the generated heat becomes too
high,
increase the resistance value or select a resistor whose allowable power is large enough. Whether or not a
braking resistor installation is necessary can be checked on the Setup Panel or Digitax SF Connect
*6）T
he minimum time interval varies depending on input format.
4 Connections
3 Preparation
When mounting drives in an enclosure such as a protection case, install a cooling device, or maintain
required clearance around it so that ambient temperature will not rise above the specied temperature.
3 Preparation
*5）
*4
)
3
5
Preparation
Setting Parameters
Digitax SF drives are equipped with a softwarebased emergency stop braking function to stop the
equipment. This emergency stop braking function does not necessarily work in case of disconnection from
control power such as drive failure and power outage.
An external citcuit is required. Please perform thorough testing before actual use.
Digitax SF Instruction Manual
