98
5. Settings
Digitax SF Instruction Manual
５. Parameters
3. Point Table Parameter List
To congure point table data by using RS-485 Communications, refer to the cross table of point table items and
their corresponding parameter numbers.
Point
No.
Position
[command
pulse]
Rotational
speed
[rpm]
Acceleration
time
[ms]
Deceleration
time
[ms]
Command
method
[-]
Dwell time
[ms]
Operation
[-]
Positioning
com
pletion
[encoder pulse]
Enable
/Disable
[-]
0 No. 722.0 No. 724.0 No. 726.0 No. 727.0 No. 720.0 No. 728.0 No. 720.1 No. 729.0 No. 720.3
1 No. 742.0 No. 744.0 No. 746.0 No. 747.0 No. 740.0 No. 748.0 No. 740.1 No. 749.0 No. 740.3
2 No. 762.0 No. 764.0 No. 766.0 No. 767.0 No. 760.0 No. 768.0 No. 760.1 No. 769.0 No. 760.3
3 No. 782.0 No. 784.0 No. 786.0 No. 787.0 No. 780.0 No. 788.0 No. 780.1 No. 789.0 No. 780.3
4 No. 802.0 No. 804.0 No. 806.0 No. 807.0 No. 800.0 No. 808.0 No. 800.1 No. 809.0 No. 800.3
5 No. 822.0 No. 824.0 No. 826.0 No. 827.0 No. 820.0 No. 828.0 No. 820.1 No. 829.0 No. 820.3
6 No. 842.0 No. 844.0 No. 846.0 No. 847.0 No. 840.0 No. 848.0 No. 840.1 No. 849.0 No. 840.3
7 No. 862.0 No. 864.0 No. 866.0 No. 867.0 No. 860.0 No. 868.0 No. 860.1 No. 869.0 No. 860.3
8 No. 882.0 No. 884.0 No. 886.0 No. 887.0 No. 880.0 No. 888.0 No. 880.1 No. 889.0 No. 880.3
9 No. 902.0 No. 904.0 No. 906.0 No. 907.0 No. 900.0 No. 908.0 No. 900.1 No. 909.0 No. 900.3
10 No. 922.0 No. 924.0 No. 926.0 No. 927.0 No. 920.0 No. 928.0
No. 920.1 No. 929.0 No. 920.3
11 No. 942.0 No. 944.0 No. 946.0 No. 947.0 No. 940.0 No. 948.0 No. 940.1 No. 949.0 No. 940.3
12 No. 962.0 No. 964.0 No. 966.0 No. 967.0 No. 960.0 No. 968.0 No. 960.1 No. 969.0 No. 960.3
13 No. 982.0 No. 984.0 No. 986.0 No. 987.0 No. 980.0 No. 988.0 No. 980.1 No. 989.0 No. 980.3
14 No. 1002.0 No. 1004.0 No. 1006.0 No. 1007.0 No. 1000.0 No. 1008.0 No. 1000.1 No. 1009.0 No. 1000.3
15 No. 1022.0 No. 1024.0 No. 1026.0 No. 1027.0 No. 1020.0 No. 1028.0 No. 1020.1 No. 1029.0 No. 1020.3
To Next Page
