Nidec Control Techniques Digitax-SF Series User Manual

4
2. Specications
1. Motor
3. Specications
Item Specifications
Ambient temperature for operation
0 to 40 ℃
Ambient humidity for operation
20 to 85 %RH （no condensation)
Ambient temperature for storage
 20 to 65 ℃ （no condensation）
(not subjected to direct sunlight) 80 ℃ for 72 hours
Ambient humidity for storage
20 to 85 %RH （no condensation）
Atmosphere for operation / storage
Indoors （not subject to direct sunlight）,
Free from corrosive gases, flammable gases, oil mist, dust, flammables, grinding fluid
Insulation resistance
≥
5 M Ω at 1,000 VDC
Dielectric strength
AC 1500 V for one minute across the primary and Ground/Earth FG
Operating altitude
≤
1,000 m
Vibration class
V15 (JEC2121)
Vibration resistance
49 m/s
2
（5 G）
Impact resistance
98 m/s
2
（10 G）
Protective structure
IP65 ： 50 W to 750 W
IP67 ： 1 kW to 2 kW
Electric shock protection
ClassⅠ（ Mandatory grounding ）
Overvoltage category
Ⅱ
Installation environment
Pollution degree 2
The brake has polarity.
Lead wire color: Connection
Yellow (BRK): +24 V
Blue (BRK 󰽌 ): GND
Incorrect wiring may result in motor failure or suboptimal performance
of the motor.
Digitax SF Instruction Manual
2 Specications
1. Motor
