Nidec Control Techniques Digitax-SF Series User Manual


DIR
PLS
DIR
PLS
DIR
PLS
DIR
PLS
A
B
A
B
A
B
A
B
CW
CCW
CW
CCW
CW
CCW
CW
CCW
Digitax SF Instruction Manual
6. Operation
2. Position Control Mode
Input Pulse Form and Parameter Setting


Pulse and Direction（PLS & DIR）（No.32.0 = ０）
Parameter
No.32.1
Parameter
No.32.3
Command input waveform
CCW CW
0
0

1
1

0

1


Quadrature phase Di󱐯erence pulse（A-Phase & B-phase）（No.32.0 = 1）
Parameter
No.32.1
Parameter
No.32.3
Command input waveform
CCW CW
0
0

1
1

0

1

Positive or Negative pulse（CCW & CW）（No.32.0 = 2）
Parameter
No.32.1
Parameter
No.32.3
Command input waveform
CCW CW
0
0

1
1

0

1








