3. Preparation
Digitax SF Instruction Manual
2. System Wiring
PCCommunicationConnector
UC60SC-MB-5ST
(HiroseElectric)
UserI/OConnector
DF02R050NA1(JAE)
MotorPowerConnector
2092-3323 (WAGOJAPAN)
AC SupplyPowerConnector
2092-3425 (WAGOJAPAN)
EncoderConnector
3E106-2230KV(3M)
USBminiB
2092-3105/002-000(WAGOJAPAN)
Wires:AWG26
Wires:
AWG22(Power),AWG24(Signal)
Wires:AWG14(UL)
orEquivalentalternatives
2092-3523/002-000(WAGOJAPAN)
Wires:AWG18(UL)
Accessories
Accessories
Plug 10150-3000-PE(3M)
Cover10350
(3M)
Connector 3E206-0100KV(3M)
Cover   3E306-3200-008(3M)
CableConnector
Name Code Pin No. Signal Description
AC Supply



Braking

Braking -
 AC Supply

 AC Supply

 AC Supply

 



 
 
 
 

 

 
 
 
 -


 
 


Drive
drives
Do not connect
