Getting Started
893-00992-E
1-39
Figure 1-26. Trunk Configuration screen for switch SW4
The Inter-Switch Trunk Configuration screen for switch SW4 is configured as
follows:
• Trunk field (read only) indicates the trunk (I1 for this switch) that
corresponds to the switch ports specified in the Trunk Members fields.
• Trunk Members indicates the ports that can be configured, in each row, to
create the corresponding trunk:
In this example, ports 3 and 6 are assigned as trunk members of trunk I1.
• STP indicates the spanning tree participation setting for each of the trunks:
In this example, trunk I1 is enabled for spanning tree participation.
• Trunk Mode indicates the Trunk Mode for each of the trunks:
In this example, the Trunk Mode field for trunk I1 is set to Enhanced. When in
this mode, the switch evenly distributes source MAC addresses to the trunk
members, balancing traffic throughout each trunk (see Note on page 1-33
).
Inter-Switch Trunk Configuration
Trunk Trunk Members STP Trunk Mode Trunk Status
----- ---------------------------- ------------ --------------- ------------
I1 [ 3 ][ 6 ][ ][ ] [ Enabled ] [ Enhanced ] [ Enabled ]
I2 [ ][ ][ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
I3 [ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
I4 [ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
Valid inter-switch trunk configurations are:
1 or 2 trunks of up to 4 links each
Up to 4 trunks of 2 links each
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
