The Inter-Switch Trunk Configuration screen for switch SW3 is configured as
follows:
• Trunk field (read only) indicates the trunk (I1 for this switch) that
corresponds to the switch ports specified in the Trunk Members fields.
• Trunk Members indicates the ports that can be configured, in each row, to
create the corresponding trunk:
Ports 1 and 2 are assigned as trunk members of trunk I1.
• STP indicates the spanning tree participation setting for each of the trunks:
In this example, trunk I1 is enabled for spanning tree participation.
• Trunk Mode indicates the Trunk Mode for each of the trunks:
In this example, the Trunk Mode field for trunk I1 is set to Enhanced. When in
this mode, the switch evenly distributes source MAC addresses to the trunk
members, balancing traffic throughout each trunk (see Note on page 1-33
).
• Trunk Status indicates the Trunk Status for each of the trunks. When set to
Enabled, the configuration settings for that specific trunk are activated.
Trunk Configuration Screen for Switch SW4
As shown in Figure 1-17, switch SW4 is set up with one inter-switch trunk
configuration (I4). This trunk connects directly to switch SW1.
As in the previous screen examples, to set up an inter-switch trunk configuration
choose Inter-Switch Trunk Configuration from the MultiLink Trunk
Configuration Menu screen.
Figure 1-26
shows the Inter-Switch Trunk Configuration screen for switch SW4.
