• Trunk Mode indicates the Trunk Mode for each of the trunks:
In this example, the Trunk Mode fields for trunks I1 and I2 are set to
Enhanced. When in this mode, the switch evenly distributes source MAC
addresses to the trunk members, balancing traffic throughout each trunk (see
Note on page 1-33
).
• Trunk Status indicates the Trunk Status for each of the trunks. When set to
Enabled, the configuration settings for that trunk are activated.
Trunk Configuration Screen for Switch SW3
As shown in Figure 1-17, switch SW3 is set up with one inter-switch trunk
configuration (I3). This trunk connects directly to switch SW1.
As in the previous screen examples, to set up an inter-switch trunk configuration
you choose Inter-Switch Trunk Configuration from the MultiLink Trunk
Configuration Menu screen.
Figure 1-25
shows the Inter-Switch Trunk Configuration screen for switch SW3.
Figure 1-25. Trunk Configuration screen for switch SW3
Inter-Switch Trunk Configuration
Trunk Trunk Members STP Trunk Mode Trunk Status
----- ---------------------------- ------------ --------------- ------------
I1 [ 1 ][ 2 ][ ][ ] [ Enabled ] [ Enhanced ] [ Enabled ]
I2 [ ][ ][ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
I3 [ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
I4 [ ][ ] [ Enabled ] [ Enhanced ] [ Disabled ]
Valid inter-switch trunk configurations are:
1 or 2 trunks of up to 4 links each
Up to 4 trunks of 2 links each
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
To Next Page
