Using the BayStack 350 Series 10/100 Autosense Switch
1-50
893-00992-E
Figure 1-33 shows the Port Mirroring Configuration screen setup for this
example.
In this example, port 12 becomes the designated Monitor Port for switch SW1
when you press [Enter] in response to the [Yes] screen prompt. The screen data
displayed at the bottom of the screen changes to show the new currently active
port mirroring configuration.
The Monitoring Mode field [ Address A - > Address B ] indicates that all
traffic transmitted by address A to address B will be monitored by the StackProbe
attached to Monitor Port 12.
Figure 1-33. Port Mirroring address-based screen example
See “Port Mirroring Configuration” on page 3-48 for a full description of the Port
Mirroring Configuration screen fields.
Note:
When you enter MAC addresses in this screen, they are also displayed
in the MAC Address Table screen (see “MAC Address Table” on page 3-24).
Port Mirroring Configuration
Monitoring Mode: [ Address A -> Address B ]
Monitor Port: [ 12 ]
Port X: [ ]
Port Y: [ ]
Address A: [ 00-44-55-44-55-22 ]
Address B: [ 00-33-44-33-22-44 ]
Is your Port mirroring configuration complete? [ Yes ]
Currently Active Port Mirroring Configuration
---------------------------------------------
Monitoring Mode: Address A <-> Address B Monitor Port: 1
Address A: 00-11-22-33-44-55 Address B: 22-33-44-55-66-77
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
