Pulse Outputs Section 5-2
■ CPU Unit with 30 I/O Points
■ CPU Unit with 40 I/O Points
■ CPU Unit with 60 I/O Points
Lower Terminal Block
(Example: Transistor Outputs)
Pulse output 0 (CCW/direction/PWM output 0)
Pulse output 0 (CW/pulse)
CIO 100
Origin search 0 (Error counter reset output)
Pulse output 1 (CW/pulse)
Origin search 1 (Error counter reset output)
Pulse output 1 (CCW/direction/PWM output 1)
CIO 101
NC
00 01 02
03
04
NC
COM
COM COM
05
COM
07
06
00 02
COM
01
03
Lower Terminal Block
(Example: Transistor Outputs)
Pulse output 0 (CCW/direction/PWM output 0)
Pulse output 0 (CW/pulse)
CIO 100
Pulse output 1 (CW/pulse)
Origin search 0 (Error counter reset output)
Origin search 1 (Error counter reset output)
CIO 101
Pulse output 1 (CCW/direction/PWM output 1)
NC
00 01 02 03
NC
COM
COM
COM
04
COM
06
02
00 01
COM
05
07
03
04
06
07
05
COM
Lower Terminal Block
(Example: Transistor Outputs)
Pulse output 0 (CW/pulse)
CIO 100
Pulse output 0 (CCW/direction/PWM output 0)
Origin search 0 (Error counter reset output)
Pulse output 1 (CW/pulse)
Pulse output 1 (CCW/direction/PWM output 1)
Origin search 1 (Error counter reset output)
CIO 101
CIO 102
NC 00 01 02 03 04 06 00 01 03 04 06 00 01 03 04 06
NC COM COM COM COM 05 07 COM 02 COM 05 07 COM 02 COM 05 07
