321
Inverter Positioning Section 5-3
Example settings of 3G3MV parameters are listed below. Refer to the
User’s
Manual
of the Inverter for details on the parameters.
Parameter
No.
Name Description Default Setting
n003 RUN command selection 0: The RUN Key and STOP/RESET Key on the
Digital Operator are enabled.
1: Multi-function input is enabled through the con-
trol circuit terminals.
2: RS-422A/485 communications are enabled.
3: Input is enabled from the optional Communica-
tions Unit.
02
n004 Frequency reference selection 0: Frequency reference adjustment
1: Frequency reference 1 (n024)
2: Frequency reference control terminal (0 to 10
V)
3: Frequency reference control terminal (4 to 20
mA)
4: Frequency reference control terminal (0 to 20
mA)
5: Pulse train reference control terminal
6: Frequency reference through RS-422A/RS-485
7: Multi-function analog voltage input (0 to 10 V)
8: Multi-function analog current input (4 to 20 mA)
9: Frequency reference input through optional
Communications Unit.
06
n005 Stopping method selection 0: Decelerates to stop
1: Coasts to stop
00
n006 Reverse rotation-prohibit
selection
0: Reverse enabled
1: Reverse disabled
00
n011 Maximum frequency (FMAX) 50.0 to 400.0 Hz (0.1-Hz increments) 60.0 Hz 60.0 Hz
(Depends
on machine
configura-
tion.)
n016 Minimum output frequency
(FMIN)
0.1 Hz to 10.0 Hz (0.1-Hz increments) 1.5 Hz 0.1 Hz
n018 Acceleration/deceleration time
setting unit
0: 0.1 s
1: 0.01 s
00
n019 Acceleration time 1 0 to 6,000 s 10.0 s 0
n020 Deceleration time 1 0 to 6,000 s 10.0 s 0
n151 RS-422A/485 communications
timeover detection selection
(The time between receiving
PLC signals is monitored, Tim-
eout time: 2 s.)
0: Detects time-over, fatal error, and the Inverter
coasts to a stop.
1: Detects time-over, detects fatal error, and the
Inverter decelerates to a stop in deceleration time
1.
2: Detects time-over, detects fatal error, and the
Inverter decelerates to a stop in deceleration time
2.
3: Detects time-over, detects nonfatal error warn-
ing, and the Inverter continues operating.
4: No time-over is detected.
00
n152 RS-422A/485 communications
frequency reference/display
unit selection
0: 0.1 Hz
1: 0.01 Hz
2: Converted value based on 30,000 decimal as
maximum frequency
3: 0.1% (Maximum frequency: 100%)
01
