Omron CP1L User Manual

ix
Procedure When the Device Type and CPU Type Are Not Known
This procedure is possible only when connected directly to the CPU Unit with
a serial connection.
If you don't know the device type and CPU type that are connected directly to
the CPU Unit on a serial line, select
PLC - Auto Online to go online, and then
select
PLC - Edit - Information from the menus.
The PLC Information Dialog Box will be displayed and can be used to confirm
the unit version of the CPU Unit.
Unit version
▲

Omron CP1L Specifications

General

Model	CP1L
Data Memory Capacity	32K words
Program Capacity	10K steps
Communication Ports	USB, RS-232C
Expansion	I/O
Pulse Output	100 kHz
Built-in I/O	Digital I/O
Expansion Slots	Supports up to 3 expansion units
Operating Voltage	100-240 VAC or 24 VDC (varies by model)
Operating Temperature	55 degrees Celsius
Storage Temperature	75 degrees Celsius
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
Shock Resistance	147 m/s^2, 3 times in X, Y, and Z directions
