PART 1: CX-Programmer
OMRON CHAPTER 2 – Quick Start Guide
CX-Programmer _Page 27
Summary
In this chapter, the programmer has been introduced to the following concepts:
• Starting the CX-Programmer application.
• CX-Programmer and projects. The CX-Programmer environment, including the project
workspace, Diagram Workspace, Mnemonics view and symbol tables.
• Getting started with CX-Programmer.
• Setting up a Ladder program.
• Writing a Ladder program.
Note: You can switch to the Smart Style Mode to use Smart Menus. This is the same mode as the
one supported by the CX-Programmer for CP1E. Select Tools - Options and then set the
Menu/Options Style on the General Tab Page to display in the Smart Style Mode (CX-
Programmer version 9.0 or higher).
