Omron CX-PROGRAMMER V9 - C200 H Device Group; C200 HE Device Group

PART 3: CX-Server Runtime
OMRON APPENDIX B – PLC Memory Areas
Revision 2.0 CX-Server Runtime_Page 63
C200H Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 27 Yes Yes Yes F C
DM 0 1999 Yes No Yes
HR 0 99 Yes Yes Yes F C
IR (opt) 0 235 Yes Yes Yes F C
LR 0 63 Yes Yes Yes F C
SR (opt) 236 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
TR 0 0 (bit 7) No Yes No
TC 0 511 Present Value Status Yes F C
Special addresses: CLOCK, MODE.
C200HE Device Group
General Memory Areas
Memory Areas for any CPU.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 27 Yes Yes Yes F C
DM 0 4095 Yes No Yes
DM 6000 6655 Yes No Yes
HR 0 99 Yes Yes Yes F C
IR (opt) 0 235 Yes Yes Yes F C
IR (opt) 300 511 Yes Yes Yes F C
LR 0 63 Yes Yes Yes F C
SR (opt) 236 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
SR (opt) 256 299 Yes Yes Yes FC
TR 0 0 (bit 7) No Yes No
SR (opt) 256 299 Yes Yes Yes F C
TC 0 511 Present Value Status Yes F C
CPU 32/42 Memory Areas
Memory Areas in addition to general memory areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
DM 4096 5999 Yes No Yes
Special addresses: CLOCK, MODE.
