Omron CX-PROGRAMMER V9 User Manual

PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 66 Revision 2.0
C200HX Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 27 Yes Yes Yes F C
DM 0 6655 Yes No Yes
HR 0 99 Yes Yes Yes F C
IR (opt) 0 235 Yes Yes Yes F C
IR (opt) 300 511 Yes Yes Yes F C
LR 0 63 Yes Yes Yes F C
SR (opt) 236 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
SR (opt) 256 299 Yes Yes Yes F C
TR 0 0 (bit 7) No Yes No
TC 0 511 Present Value Status Yes F C
EM 0 6143 * 3 Yes No Yes -n
Special addresses: CLOCK, MODE, BANKNO.
C200HX-Z Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 27 Yes Yes Yes F C
DM 0 6655 Yes No Yes
HR 0 99 Yes Yes Yes F C
IR (opt) 0 235 Yes Yes Yes F C
IR (opt) 300 511 Yes Yes Yes F C
LR 0 63 Yes Yes Yes F C
SR (opt) 236 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
SR (opt) 256 299 Yes Yes Yes F C
TR 0 0 (bit 7) No Yes No
TC 0 511 Present Value Status Yes F C
EM 0 6143 * 3 Yes No Yes -n
CPU 65 Memory Areas
Memory Areas in addition to general memory areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
EM 0 6143 * 8 Yes No Yes -n
CPU 85 Memory Areas
Memory Areas in addition to general memory areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
EM 0 6143 * 16 Yes No Yes -n
Special addresses: CLOCK, MODE, BANKNO.
