PART 1: CX-Programmer
OMRON CHAPTER 6 – Converting a C500/C120/C**P Program to CS/CJ/CP/CVM1 Format
CX-Programmer _Page 117
C500/C120/C**P Compare
It is possible to compare UM and DM/HR area data saved in a file and data in a C500/C120/C**P PLC. Select
Tools – C500/C120/CxxP Support – Compare PLC and File.
C500/C120/C**P Operating Mode Change
It is possible to change the operating mode of the connected PLC to RUN, MONITOR, or PROGRAM mode.
Select Tools – C500/C120/CxxP Support – Operating Mode.
Conversion Table for C500/C120/C**P Instructions
When the PLC model is changed using the C500/C120/C**P utility, the programs are automatically converted.
The instructions (mnemonics) and operands are converted so that they function the same way as before
conversion. However, there are some exceptions.
Refer to the Instruction Conversion Table below for the conversion details and the constants used in the
operands. Refer to the Memory Area Conversion Table and Auxiliary Area Conversion Table for the memory
addresses used in the operands.
“CS/CJ Series” in the tables indicates the CJ2H, CS/CJ-H, CJ1M, CS1D, and CP1 PLCs. “CV Series” indicates
CVM1-V2 PLCs.
Before conversion
After conversion
C500
/C120
C**P Example
CS/CJ
Series
Example CV Series Example Remarks
LD LD 0001 LD 000001 LD 000001 ---
LD NOT LD NOT 0001 LD NOT 000001 LD NOT 000001 ---
AND AND 0001 AND 000001 AND 000001 ---
AND NOT AND NOT 0001 AND NOT 000001 AND NOT 000001 ---
OR OR 0001 OR 000001 OR 000001 ---
OR NOT OR NOT 0001 OR NOT 000001 OR NOT 000001 ---
AND LD AND LD AND LD AND LD ---
OR LD OR LD OR LD OR LD ---
OUT OUT 0100 OUT 000100 OUT 000100 ---
OUT NOT OUT NOT 0100 OUT NOT 000100 OUT NOT 000100 ---
TIM TIM 00 #100 TIM 0000 #0100 TIM 0000 #0100 ---
CNT CNT 10 #0003 CNT 0010 #0003 CNT 0010 #0003 ---
NOP NOP NOP NOP ---
END END END END ---
IL IL IL IL ---
ILC ILC
Same as before
conversion
ILC
Same as
before
conversion
ILC ---
JMP JMP JMP0 JMP0 JMP #0000
JME JME JME0 JME0
JME #0000
- The following message will
appear:
“CONVERT_WARNING:
The instruction specification
is different. Check the
instructions.” Check the
specifications of CPU Unit
after conversion.
- These instructions do not
have operands for the
C500/C120/C**P.
- For the CS/CJ-H PLCs,
JMP and JME are
converted to their
corresponding instructions,
JMP0 and JME0,
respectively.
- For the CV Series, a fixed
value #0000 is added as an
operand.
FAL FAL 01
Same as before
conversion
FAL 01 #FFFF FAL 001 #FFFF
FAL
00
FAL 00 FAL 0 FAL 0 #FFFF FAL 000 FAL 000 #FFFF
FALS
(None)
FALS 01 FALS 01 #FFFF FALS 001 #FFFF
These instructions have
only one operand for the
C500/C120/C**P. After
conversion, a fixed value of
#FFFF is added as the
second operand.
SFT SFT 00 01 SFT 0000 0001 SFT 0000 0001 ---
KEEP KEEP 0000 KEEP 000000 KEEP 000000 ---
CNTR CNTR 000 #1000 CNTR 0 #1000 CNTR 0000 #1000 ---
DIFU DIFU 0000
Same as before
conversion
DIFU 000000
Same as
before
conversion
DIFU 000000 ---
To Next Page
