Omron CX-PROGRAMMER V9 User Manual

PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 78 Revision 2.0
CS1H Device Group
General Memory Areas
General Memory Areas for all CPUs 63, 64, 65, 66 and 67.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
IR 0 15 Yes (double) No Yes
DR 0 15 Yes No Yes f c
TK 0 31 Status Yes No
A 0 447 Yes Yes No
A 448 959 Yes Yes Yes f
H 0 511 Yes Yes Yes
W 0 511 Yes Yes Yes
CIO (opt) 0 6143 Yes Yes Yes f c
T 0 4095 Present Value Status Yes F C
C 0 4095 Present Value Status Yes F C
D 0 32767 Yes No Yes
CF 0 11 No Yes No
CF 100 104 No Yes No
CF 113 114 No Yes No
CPU 64 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
E 0 32767 * 1 Yes No Yes -n
CPU 65 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
E 0 32767 * 3 Yes No Yes -n
CPU 66 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
E 0 32767 * 7 Yes No Yes -n
CPU 67 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
E 0 32765 * 13 Yes No Yes -n
Special
addresses:
(all CPUs):
(CPU 64/65/66/67):
CLOCK, MODE.
BANKNO.
