PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 68 Revision 2.0
CJ2H-CPU67(-EIP) Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
E 0 32767*15 Yes Yes Yes
Note: Bits in EM banks 7 to E can be force-set and force-reset (Enable Forced Set/Forced Clear).
CJ2H-CPU68(-EIP) Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
E 0 32767*25 Yes Yes Yes
Note: Bits in EM banks 11 to 18 can be force-set and force-reset (Enable Forced Set/Forced Clear).
CJ2M-CPU11/12/13/31/32/33 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
E 0 32767*1 Yes Yes Yes
Note: Force-setting/resetting bits can be enabled by using an EM memory setting.
CJ2M-CPU14/15/34/35 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
E 0 32767*4 Yes Yes Yes
Note: Force-setting/resetting bits can be enabled by using an EM memory setting.
CJ1G Device Group
General Memory Areas
General Memory Areas for all CPUs 44 and 45.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
IR 0 15 Yes (double) No Yes
DR 0 15 Yes No Yes f c
TK 0 31 Status Yes No
A 0 447 Yes Yes No
A 448 959 Yes Yes Yes f c
H 0 511 Yes Yes Yes
W 0 511 Yes Yes Yes
CIO (opt) 0 6143 Yes Yes Yes f c
T 0 4095 Present Value Status Yes F C
C 0 4095 Present Value Status Yes F C
D 0 32767 Yes No Yes
CF 0 11 No Yes No
CF 100 104 No Yes No
CF 113 114 No Yes No
