Omron CX-PROGRAMMER V9 User Manual

PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 80 Revision 2.0
CPU 67 Memory Areas
Memory Areas in addition to General Memory Areas
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
E 0 32767*13 Yes No Yes -n
IDSC Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 27 Yes Yes Yes F C
DM 0 1023 Yes No Yes
DM 6144 6655 Yes No Yes
HR 0 99 Yes Yes Yes F C
IR (opt) 0 243 Yes Yes Yes F C
LR 0 63 Yes Yes Yes F C
SR (opt) 244 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
TR 0 0 (bit 7) No Yes No
TC 0 511 Present Value Status Yes F C
Special addresses: CLOCK, MODE.
SRM1 Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
AR 0 15 Yes Yes Yes F C
DM 0 2047 Yes No Yes
DM 6144 6655 Yes No Yes
HR 0 19 Yes Yes Yes F C
IR (opt) 0 23 Yes Yes Yes F C
IR (opt) 200 252 Yes Yes Yes F C
LR 0 15 Yes Yes Yes F C
SR (opt) 232 252 Yes Yes Yes F C
SR (opt) 253 255 (bit 7) Yes Yes No
TR 0 0 (bit 7) No Yes No
TC 0 127 Present Value Status Yes F C
Special addresses: MODE.
