Omron CX-PROGRAMMER V9 - CV2000 Device Group; CV500 Device Group

PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 82 Revision 2.0
CV2000 Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
A 0 255 Yes Yes Yes F C
A 256 511 Yes Yes No
AC 0 2047 No Yes No
C 0 1023 Present Value Status Yes F C
CIO (opt) 0 2555 Yes Yes Yes F C
D 0 24575 Yes No Yes
DR 0 2 Yes No Yes
G 0 255 Yes Yes Yes F C
IR 0 2 Yes No Yes
ST 0 1023 Yes Yes Yes
T 0 1023 Present Value Status Yes F C
TN 0 1023 No Yes Yes F C
TR 0 0 (bit 7) No Yes Yes F C
E 0 32765 * 2/4/8 Yes No Yes - n
Special addresses: BANKNO, CLOCK, MODE.
CV500 Device Group
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
A 0 255 Yes Yes Yes F C
A 256 511 Yes Yes No
AC 0 1023 No Yes No
C 0 511 Present Value Status Yes F C
CIO (opt) 0 2555 Yes Yes Yes F C
D 0 8191 Yes No Yes
DR 0 2 Yes No Yes
G 0 255 Yes Yes Yes F C
IR 0 2 Yes No Yes
ST 0 511 Yes Yes Yes F C
T 0 511 Present Value Status Yes F C
TN 0 511 No Yes Yes F C
TR 0 0 (bit 7) No Yes Yes F C
Special addresses: MODE, CLOCK
