Omron CX-PROGRAMMER V9 User Manual

PART 3: CX-Server Runtime
APPENDIX B – PLC Memory Areas OMRON
CX-Server Runtime_Page 84 Revision 2.0
CPU 01 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
C 0 511 Present Value Status Yes F C
D 0 8191 Yes No Yes
T 0 511 Present Value Status Yes F C
CPU 11 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
C 0 1023 Present Value Status Yes F C
D 0 24575 Yes No Yes
T 0 1023 Present Value Status Yes F C
CPU 21 Memory Areas
Memory Areas in addition to General Memory Areas.
Prefix Start Channel End Channel
Word
Addr
essin
g
Bit
Addressing
Read
Write
Modifiers
C 0 1023 Pres
ent
Value
Status Yes F C
D 0 24575 Yes No Yes
T 0 1023 Pres
ent
Value
Status Yes F C
E 0 32765 * 2/4/8 Yes No Yes -n
Special
addresses:
(all CPUs):
(CPU 21):
CLOCK, MODE.
BANKNO.
FinsGateway CPU Unit
Prefix
Start
Channel
End Channel
Word
Addressing
Bit
Addressing
Read
Write
Modifiers
CIO (opt) 0 32767 Yes Yes Yes
D 0 32767 Yes No Yes
