Omron CX-PROGRAMMER V9 User Manual

PART 1: CX-Programmer
CHAPTER 6 – Converting a C500/C120/C**P Program to CS/CJ/CP/CVM1 Format OMRON
CX-Programmer _Page 122
Auxiliary Area Conversion Table
The addresses of the special auxiliary relays used in the operands are automatically converted as shown below.
Before conversion After conversion
Name
C500/C120 C**P CS/CJ Series CV Series
PC Link Level 1, Units 8 to 15 Run Flags
58.00 to
58.07
PC Link Level 1, Units 8 to 15 Error
Flags
58.08 to
58.15
Remote I/O Error Flags
59.00 to
59.15
SYSMAC NET Error Flag 60.03
SYSMAC NET Run Flag 60.04
SYSMAC NET Data Link Run Flag 60.05
CPU-mounting Host Link Error Flag 60.08
CPU-mounting Host Link Restart Bit 60.09
Same as before conversion
Data Retention Flag (IOM Hold Bit) 60.12 A500.12 A0.12
Rack-mounting Host Link Restart Bit 60.13 Same as before conversion
Load-off control (Output OFF Bit) 60.15 A500.15 P_Output_Off_Bit A0.15 P_Output_Off_Bit
1 FAL code 61.00 A400.00
2 FAL code 61.01 A400.01
4 FAL code 61.02 A400.02
8 FAL code 61.03 A400.03
1×10 FAL code
61.04 A400.04
2×10 FAL code
61.05 A400.05
4×10 FAL code
61.06 A400.06
8×10 FAL code
61.07
(None)
A400.07
Battery alarm flag (Battery Error Flag) 61.08 18.08 A402.04 P_Low_Battery
Scan Time Error Flag 61.09 18.09 A401.08 P_Cycle_Time_Error
I/O Verification Error Flag 61.10 A402.09 P_IO_Verify_Error
High-speed Counter Hardware Reset
Flag (ON for 1 scan only)
18.10
Rack-mounting Host Link Unit Error Flag 61.11
Same as before conversion
Remote I/O Error Flag 61.12 A402.05
Always ON Flag 61.13 18.13 CF113 P_On A500.13 P_On
Always OFF Flag 61.14
18.11
18.12
18.14
CF114 P_Off A500.14 P_Off
First Scan Flag (ON for 1 scan only) 61.15 18.15 A200.15 P_First_Cycle A500.15 P_First_Cycle_Task
PC Link level 0, Units 0 to 7 Run Flags
62.00 to
62.07
PC Link level 0, Units 0 to 7 Error Flags
62.08 to
62.15
Same as before conversion
0.1-second clock pulse 63.00 19.00 CF100 P_0_1s A501.00 P_0_1s
0.2-second clock pulse 63.01 19.01 CF101 P_0_2s A501.01 P_0_2s
1.0-second clock pulse 63.02 19.02 CF102 P_1s A501.02 P_1s
Error (ER) flag 63.03 19.03 CF003 P_ER A500.03 P_ER
Carry (CY) Flag 63.04 19.04 CF004 P_CY A500.04 P_CY
Greater Than (GR) Flag 63.05 19.05 CF005 P_GT A500.05 P_GT
Equals (EQ) Flag 63.06 10.06 CF006 P_EQ A500.06 P_EQ
Less Than (LE) Flag 63.07 19.07 CF007 P_LT A500.07 P_LT
