PART 1: CX-Programmer
APPENDIX C – Smart Input Mode OMRON
CX-Programmer _Page 138
Inputting Special Instructions
Example: Entering MOV D0 D100
1, 2, 3…
1. Press the M Key.
A list of the instructions starting with “M” will be displayed.
2. Press the Enter Key or the Space Key.
The top instruction in the list (MOV) will be entered, and the first operand will be
displayed.
Note: If the first candidate is OK, the operand can be input immediately, without inputting the Enter or
Space Key.
3. Enter “D0” and press the Enter Key or the Space Key.
“MOV D0” will be entered, and the second operand will be displayed.
4. Enter “D100.”
“MOV D0 D100” will be entered.
(If necessary, you can go back one character at a time by pressing the Back Space Key.)
