PART 2: CX-Server PLC Tools
CHAPTER 7 – Memory Card Component OMRON
CX-Server PLC Tools_Page 78
Note: With the CX-One Ver 1.1 (CX-Programmer Ver. 6.1) and later versions, the following
functions can be executed if the PLC model is set to CP1H.
1, 2, 3…
1. Memory Cassette Transfer function
Data can be transferred and verified between the Memory Cassette and CP1H CPU Unit.
♦ Applicable Data
The following table lists the kinds of data that can be selected for transfer/verification.
Applicable data
Program, parameters, Data Memory, variable tables, comments, program index, and Data Memory
initial values
♦ Procedure
Select PLC – Edit – Memory Cassette/DM and click the Transfer to Memory Cassette,
Transfer to PLC, or Verify All Areas Button.
2. Data Memory to Flash Memory Backup function
All of the Data Memory in the CP1H CPU Unit’s internal RAM can be backed up as DM
initial values in the CPU Unit’s internal flash memory. The backed up data is known as
Backup DM (DM initial values).
♦ Procedure
Select PLC – Edit – Memory Cassette/DM and click the Backup Button in the Backup to
Flash Memory Field.
To Next Page
