PART 2: CX-Server PLC Tools
CHAPTER 10 – Data Links OMRON
CX-Server PLC Tools_Page 94
Menu Sub-menus/
Commands
Function
Exit Exits the Datalink Component window.
Move Right Moves the cursor to the right in the Data Link Configuration window.
Move Left Moves the cursor to the left in the Data Link Configuration window.
Move Up Moves the cursor up in the Data Link Configuration window.
Move Down Moves the cursor down in the Data Link Configuration window.
Change Window Changes the active window.
Zoom Out Zooms out from within the Data Link Configuration window.
Zoom In Zooms in within the Data Link Configuration window.
Zoom Original Returns the Data Link Configuration window to its initial scale.
Show in List Shows the Data Link Area settings in list format.
Show in Table Shows the Data Link Area settings in table format.
Show Func Bar Shows function key guides at the bottom of the Datalink Component
window. (Enabled for table format only.)
View
Show Offset Shows the specified offset value on the Node Editing window.
Wizard Executes the Datalink Wizard.
Add Source Link Adds a node to the data links.
Add Destination Adds the receive area of a participating node to the data links.
Delete Deletes nodes.
Validate Table Checks data link tables.
Table Information Edits data link table information.
Show Node List Displays a list of nodes.
Table
Redraw Resets colored displays.
Transfer from PLC Uploads online data link tables to the computer.
Transfer to PLC Downloads online data link tables from the computer to a PLC.
Verify Node Compares data link tables generated by CX-Net with data link tables
stored in the PLC. If they do not match, a error dialog box is displayed.
Data Link
Operation/Status
Displays the operation and data link status of manually set data links.
Automatic Data
Link Setup
Sets parameters for automatically set data links, and transfers them to
the startup node.
Set All Nodes for
Network Operation
Executes transfer, verify, and delete operations for all nodes.
Show All Network
Nodes
Reads data link tables from all nodes.
Online
Delete Deletes data link tables.
Options Cycle Time Sets the communications cycle time (for SYSMAC LINK data link
tables only).
Help Displays help.
