PART 2: CX-Server PLC Tools
CHAPTER 12 – PLC Backup Tool OMRON
CX-Server PLC Tools_Page 152
3. Select the Units that you want to back up by selecting the boxes in the number column, and
then click the Next Button.
The Backup from PLC (2/2) Dialog Box will be displayed so you can enter attributes for
the backup file.
Enter comments for the backu
rocedure.
Destination Folder:
Shows the destination folder where the backup file will be saved. As a default, a folder
with the current date and time as the folder name (YYMMDD_HHMMSS) will be
automatically created.
Example: If the file was created on January 31st 2008, at 11:28:17, the folder name will
be 080131_112817.
User Name:
Input the name of the user.
Backup Date/Time:
The current date and time from the computer are
displayed here.
Click this button to
change the backup
folder.
4. Specify where to save the backup file.
The default is C:\Backup.
Click the button next to the backup folder field to change the backup folder or edit the
folder name directly.
5. Enter the user name and comments.
6. Click the Start Button.
An Uploading Dialog Box will be displayed to indicate that the backup operation is being
executed.
Shows the progress of
the backup operation.
Displays the backup status.
Note: If the read protection has been set for the connected PLC, the protection must be
cleared before the data can be backed up.
Refer to Clearing UM and Task Read Protection, below, for details.
